- Product Introduction
- Product message
Features:
• Insulation class H | • Motor anti-vibration mounted |
• Flue temperature:≤180C°(continuous) | • Housing & impeller: aluminized sheet steel |
≤240C°(continuous) | • Mounting position Vertical installation to support |
Model | Voltage (V) | Frequency (Hz) | Input power (W) | Current (A) | Speed (RPM) | Air volume (M3/h) | Static pressure (Pa) |
FL150020D-01 | 230 | 50 | 40 | 0.35 | 4000 | 160 | 540 |
FL150020D-02 | 12 | - | 42 | 3.52 | 4000 | 160 | 540 |
FL150020D-03 | 24 | - | 41 | 1.7 | 4000 | 160 | 540 |
