Single Shaft

A/Phase

N.m min.

Ω/Phase @20℃

Mh/Phase

g.cm²

kg

mm

mm

CSM253BL10A

1

0.8

4.2

9

140

0.46

42.5

φ6.35/φ8

CSM253BL20A

2

1.2

2.8

CSM254BL20A

2

1

1.3

2.9

180

0.52

45.5

CSM254BL30A

3

0.6

1.3

CSM255BL30A

3

1.5

0.7

2.4

280

0.72

55.5

CSM255BL40A

4

0.4

1.3

CSM256BL30A

3

1.8

0.9

3

350

0.86

65.5

CSM256BL40A

4

0.5

1.6

CSM257BL30A

3

2.3

1.1

4.8

480

1.06

76.5

CSM257BL50A

5

0.4

1.5

CSM250BL40A

4

3.2

0.9

3.8

580

1.4

101

φ8/φ10

CSM250BL50A

5

0.5

2.8

②

Step Angel

2:1.8°

③

Frame Size

5:NEMA23 □57mm

④

Motor Length Code

3:42.5mm    4: 45.5mm  5:55.5mm  6:65.5mm

7:76.5mm    8: 80.5mm  9:85.5mm  10:101mm

⑤

Motor Connection Type

B:Bipolar
  U:Unipolar

P: Plug in Connector

L: Lead Wire Type

C: Cable Type

⑥

Rated Current

50:    5A/Phase

⑦

Motor Type

A:Single Shaft B:Dual Shaft
  E:Encoder Mounting Hole & Dual Shaft

⑧

Shaft Code

8:8mm I:6.35mm

⑨

Design Code

01:No.1 Customized motor

⑩

Options

Brake Option

BK

Encoder Option

ED1K:1000CPR 2-channel Differential   Output
  ED2K5Z:2500CPR 3-channel Differential Output

Plantary

PG10: Ratio:10:1
